No. | Technical Data | Parameter Data |
01 | Daily production | 10Ton/day |
02 | Refrigeration capacity | 75.9KW |
03 | Evaporative temperature | -20℃ |
04 | Condenser temperature | 38℃ |
05 | Standard ambient temperature | 25℃ |
06 | Standard water inlet temperature | 20℃ |
07 | Total installation power | 40KW |
08 | Circulation pump input power | 3.7KW |
09 | Cooling tower input power | 0.75KW |
10 | Compressor input power | 34.1KW |
11 | Gearbox power | 0.55KW |
12 | Water pump power | 0.37KW |
13 | Water supply pressure | 0.1Mpa-0.5Mpa |
14 | Refrigerant | R404a |
15 | Ice temperature | -5℃ |
16 | Ice thickness | 1.5mm~2.2mm |
17 | Water consumption | 0.42M³/h |
18 | Water pipe diameter | 3/4'' |
19 | Unit weight | 1680kg |
20 | Ice machine dimension (L*W*H) | 3200*1900*1750mm |
